Kymron
RH14G Mini Track Excavator
This excavator has a 14hp Briggs and Stratton gas engine. The RH14G comes in different color options. This is our basic model that is priced in the budget spectrum, but still has an upgraded hydraulic pump unlike the competition. This machine weighs 2,200 lbs and can lift upward of 1,500 lbs! The RH14G has an ergonomic control console placement so you can sit up straight in the operator station and operate comfortably. Our exclusive design is set up to allow name brand Hydraulic Pumps, Drives and Motors from Parker USA and Eaton USA to be installed as direct replacements on our machinery. Low cost of ownership compared to a big brand unit, which would run you upwards of $28,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Height: 7’ 2”
- Total Width: 37”
- Track Width: 7”
- Track Length: 48”
- Track to Blade: 54”
Specifications:
- Max. Digging Depth: 5’ 8”
- Max. Digging Height: 8’ 7”
- Max. Digging Radius: 9’ 4”
- Max. Dumping Height: 6’
Price: $8,300
w/ side swing boom $9,100
Fully loaded w/ side swing boom + retractable tracks $9,900
(3 Year Powertrain Warranty)
XH20D Mini Track Excavator
This excavator has a Yanmar diesel engine and the Side Swing Boom included as a standard feature. The XH20D has smooth pilot hydraulics along with some other notable features, including digital gauges and foot pedal thumb operation. The XH20D has wider and longer tracks with a zero-swing radius and is a step up from our popular RH14G. This machine also includes the hydraulic thumb as a standard feature. It has an upgraded directional spool valve block that is manufactured in Italy to the tightest of tolerances. The XH20D comes in different color options and can lift weight upwards of 1800 lbs. This machine weighs 3,500 lbs with a max digging force of 2,123 lbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $40,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Height: 7’ 2”
- Total Width: 37”
- Track Width: 7”
- Track Length: 48”
- Track to Blade: 54”
Specifications:
- Max. Digging Depth: 5’ 8”
- Max. Digging Height: 8’ 7”
- Max. Digging Radius: 9’ 4”
- Max. Dumping Height: 6’
Price: $18,500
Optional factory installed cab w/ Radio & Heat $1,500
Optional Dealer installed metal tracks $1,500
(3 Year Powertrain Warranty)
ZX16D Mini Excavator
The ZX16D Mini Excavator comes in different color options and features a High Quality hydraulic pump along with internal boom mounted hydraulic lines for maximum protection. Some other notable features include the opening body hood for easy maintenance access. It has a zero-tail swing machine with ergonomic pilot controls and has 2 speed piston drive motors.
The ZX16D is a premium unit with load-sensing hydraulics that is manufactured to the tightest of tolerances to make a smooth comfortable operation.
It includes the factory installed side swing feature, which allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences.​ The ZX16D also includes the factory installed retractable tracks which can make the overall width of the machine 30” – wide to fit through tight spaces or extended them out to make the overall width 38” wide. 10.2KW Kubota Diesel engine.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
- Retractable tracks
Dimensions:
- Total Length: 9’ 11”
- Total Height: 7’ 5”
- Total Width: 30” - 38”
- Track Width: 7”
- Track Length: 51”
Special Order – Price: $15,900
(Fully Loaded – 3 Year Powertrain Warranty)
ZX22D Mini Excavator
The 2026 ZX22D Mini Excavator comes in different color options and features an high quality variable-displacement plunger hydraulic pump along with internal boom mounted hydraulic lines for maximum protection. The ZX22D has a Yanmar Engine and weighs 4,000 lbs.
The ZX22D is a zero-tail swing machine with ergonomic pilot controls and has 2-speed piston drive motors to get you from point A to point B on the jobsite. Load-sensing hydraulics are manufactured to the tightest of tolerances to make a smooth comfortable operation.
This mini excavator includes the factory installed side swing feature, which allows the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences. Also included are the factory installed retractable tracks, which can be retracted in to make the overall width of the machine 38” to fit through tight spaces or extended them out to make the overall width 50” wide. Low cost of ownership compared to a big brand unit, which would run you upwards of $32,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Height: 7’ 8”
- Total Width: 39”
- Track Width: 9”
- Track Length: 5’
- Retractable Tracks: 38” - 50”
Specifications:
- Max. Digging Depth: 7’ 7”
- Max. Reach: 11’ 4”
- Aux. Hydraulic Flow Rate: 10.3 GPM
Special Order – Price: $22,900
(Fully Loaded – 3 Year Powertrain Warranty)
XH24 Mini Excavator
This is one of our pro series models with smooth operation controls for precise operation. It features a comfortable seat with head rest and armrest. The XH24 has an exclusive variable speed plunger pump, adding 30% more power compared to a gear pump.
The factory installed Side Swing Feature allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences. With all excavators you still have the ability to swing your cab 360° in both directions as well.
The XH24 also includes the factory installed retractable tracks which can be retracted in to make the overall width of the machine 47” wide to fit through tight spaces or extended them out to make the overall width 59” wide along with 2 speed drive motors to get from to get around the job fast. ​This excavator weighs 5,000 lbs.
​
Also includes a spool valve block that is manufactured to the tightest of tolerances to make a smooth comfortable operation. The XH24 comes in different color options. Low cost of ownership compared to a big brand unit, which would run you upwards of $60,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Height: 7’
- Total Width: 47”
- Track Width: 12”
- Track Length: 7’
- Retractable Tracks: 47” - 59”
Specifications:
- Max. Digging Depth: 8’
- Max. Digging Height: 12’ 9”
- Max. Digging Radius: 13’ 2”
- Max. Dumping Height: 9’ 6”
Special Order – Price: $27,200​
Optional Features:
- All Glass Rain Cab $1,700
- Cab located Hydraulic Quick Attach $1,300
- Metal Tracks $1,400
(3 Year Powertrain Warranty)
XH32D Excavator
Pro series excavator with luxuries like Heat/AC & an adjustable seat, along with 2 speed drives. This excavator has a reliable Kubota engine. The XH32D comes with many different options and in different color options.
This version includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences.
The advantage of XH32 machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors that are available in the USA. 3 Year Powertrain Warranty. Has a 6,000 lbs. operating weight. Low cost of ownership compared to a big brand unit, which would run you upwards of $79,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Length: 13’ 9”
- Total Height: 8’ 2”
- Total Width: 61”
- Track Width: 11 1/2”
- Track Length: 6’8"
Specifications:
- Max. Digging Depth: 9’ 3”
- Max. Digging Height: 14’ 6”
- Max. Digging Outward Reach: 18’
- Max. Dumping Height: 9’ 10”
Special Order – Price: $37,200
Optional Features:
- Cab located Hydraulic Quick Attach $1,100
- Metal Tracks $2,200
- 50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
XH42D Excavator
Pro series excavator with luxuries like Heat/AC & an adjustable seat, along with 2 speed drives. This excavator has a reliable Kubota D1703 engine. The XH42D comes with many different options and in different color options.
This version includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences.
The advantage of XH42D machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors that are available in the USA. Has a 8,400 lbs. operating weight. Low cost of ownership compared to a big brand unit, which would run you upwards of $84,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Length: 16’ 2”
- Total Height: 8’ 3”
- Total Width: 68”
- Track Width: 12”
- Track Length: 7’
Specifications:
- Max. Digging Depth: 10’ 8”
- Max. Digging Height: 15’ 9”
- Max. Digging Outward Reach: 18’
- Max. Dumping Height: 11’ 2”
Special Order – Price: $42,900
Optional Features:
- 4 way Tilting Dozer Blade $2,200
- 6 way Tilting Dozer Blade $4,400
- Cab located Hydraulic Quick Attach $1,300
- Metal Tracks $2,200
-50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
XH68 Excavator
2026 XH68 KYMRON Mini Track Excavator is our top-of-the-line pro series excavator with luxuries like AC & Heated Cab with a radio. This excavator has a KUBOTA Turbo Engine. The XH68 comes with many different options and in different color options.
The advantage of KYMRON machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors for easy parts availability. Bucket Digging Force 10,990 lbs. Arm digging force 7,990 lbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $115,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Length: 19’ 6”
- Total Height: 8’ 2”
- Total Width: 78”
- Track Width: 16”
- Track Length: 8’ 4”
Specifications:
- Max. Digging Depth: 12’ 6”
- Max. Digging Height: 19’ 4”
- Max. Digging Outward Reach: 14’ 11”
- Max. Dumping Height: 13’ 10”
Special Order – Price: $57,900
Optional Features:
- 4 way tilting dozer blade $2,900
- Cab located Hydraulic Quick Attach $1,300
- Rubber Track Block System $1,500
-Cab located Hydraulic Quick hitch $1,300
-50% or 20% Black Tint Transparency $650
