Kymron Mini Excavators
RH14G Mini Track Excavator
This excavator has a 14hp Briggs and Stratton gas engine.
The RH14G comes in different color options. This is our
basic model that is priced in the budget spectrum, but still
has an upgraded hydraulic pump unlike the competition.
This machine weighs 2,200 lbs and can lift upward of 1,500
lbs! 7 GPM flow. Bucket Dig Force is 3000 lbs and Arm
breakout force is 2500 lbs. Bucket is 16". The RH14G has
an ergonomic control console placement so you can sit up
straight in the operator station and operate comfortably.
Our exclusive design is set up to allow name brand
Hydraulic Pumps, Drives and Motors from Parker USA and
Eaton USA to be installed as direct replacements on our
machinery. Low cost of ownership compared to a big
brand unit, which would run you upwards of $28,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Height: 7’ 2”
- Total Width: 37”
- Track Width: 7”
- Track Length: 48”
- Track to Blade: 54”
Specifications:
- Max. Digging Depth: 5’ 5”
- Max. Digging Height: 8’ 7”
- Max. Digging Radius: 9’ 4”
- Max. Dumping Height: 6’
Price (w/ side swing boom): $9,100
Fully loaded w/ side swing boom + retractable tracks $9,900
(3 Year Powertrain Warranty)
XH20D Mini Track Excavator
This excavator has a Yanmar diesel engine and the Side Swing Boom included as a standard feature. The XH20D has smooth pilot hydraulics along with some other notable features, including digital gauges and foot pedal thumb operation. The XH20D has wider and longer tracks with a zero-swing radius and is a step up from our popular RH14G. Bucket is 16". This machine also includes the hydraulic thumb as a standard feature. It has an upgraded directional spool valve block that is manufactured in Italy to the tightest of tolerances. 9 GPM flow. Bucket Dig Force is 3400 lbs and Arm breakout force is 2800 lbs. The XH20D comes in different color options and can lift weight upwards of 1800 lbs. This machine weighs 3,500 lbs. 11.2KW Yanmar Diesel. 22.5HP Hydraulic Pump Output. Low cost of ownership compared to a big brand unit, which would run you upwards of $40,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Height: 7’ 3”
- Total Width: 37”
- Track Width: 7”
- Track Length: 48”
- Track to Blade: 54”
Specifications:
- Max. Digging Depth: 6’ 9”
- Max. Digging Height: 10’ 7”
- Max. Digging Radius: 12’ 4”
- Max. Dumping Height: 7’ 7"
Price: $18,500
Optional factory installed cab w/ Radio & Heat $1,500
Optional Dealer installed metal tracks $1,500
(3 Year Powertrain Warranty)
XH24D Excavator
This is one of our pro series models with smooth operation controls for precise operation. It features a comfortable seat with head rest and armrest. The XH24 has an exclusive variable speed plunger pump, adding 30% more power compared to a gear pump. 19KW Kubota Diesel engine.
The factory installed Side Swing Feature allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences. With all
excavators you still have the ability to swing your cab 360° in both
directions as well. Bucket Dig Force is 4000 lbs and Arm breakout
force is 2800 lbs. Bucket is 17" wide.
The XH24 also includes the factory installed retractable tracks which can be retracted in to make the overall width of the machine 47" wide to fit through tight spaces or extended them out to make the overall width 59" wide along with 2 speed drive motors to get from to get around the job fast. This excavator weighs 5,000 lbs and has lift force of 1750 Ibs.
Also includes a spool valve block that is manufactured to the tightest of tolerances to make a smooth comfortable operation. 15.9 GPM Flow. The XH24 comes in different color options. Low cost of ownership compared to a big brand unit, which would run you upwards of $60,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Height: 7’
- Total Width: 47”
- Track Width: 12”
- Track Length: 7’
- Retractable Tracks: 47” - 59”
Specifications:
- Max. Digging Depth: 8’
- Max. Digging Height: 12’ 9”
- Max. Digging Radius: 13’ 2”
- Max. Dumping Height: 9’ 6”
Special Order – Price: $27,200​
Optional Features:
- All Glass Rain Cab $1,700
- Cab located Hydraulic Quick Attach $1,300
- Metal Tracks $1,400
(3 Year Powertrain Warranty)
Pro series excavator with luxuries like Heat/AC & an adjustable seat, along with 2 speed drives. This excavator has a reliable Kubota 19KW Diesel engine. This comes with many different options and in different color options.
This version includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences. Bucket is 20" wide.
The advantage of XH32 machines is our exclusive design
which is set up to allow name brand Hydraulic Pumps. Drives and Motors that are available in the USA. 16.3 GPM flow rate. Bucket digging force 5,283 lbs. Arm digging force 3,147 lbs. Has a 6,000 lbs operating weight and has lift force of 2,300 lbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $79,000.
XH32D Excavator
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Length: 13’ 9”
- Total Height: 8’ 2”
- Total Width: 61”
- Track Width: 11 1/2”
- Track Length: 6’8"
Specifications:
- Max. Digging Depth: 9’ 3”
- Max. Digging Height: 14’ 6”
- Max. Digging Radius: 15’ 4"
- Max. Dumping Height: 9’ 10”
Special Order – Price: $37,200
Optional Features:
- Cab located Hydraulic Quick Attach $1,100
- Metal Tracks $2,200
- 50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
Pro series excavator with luxuries like Heat/AC & an adjustable seat, along with 2 speed drives. This excavator has a reliable Kubota 19KW Diesel D1703 engine. The XH42D comes with many different options and in different color options.
This version includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to get into tight spaces and position the boom to dig parallel to walls and fences. Max digging height is 15' 9". Bucket is 24" wide.
The advantage of XH42D machines is our exclusive design which is set up to allow name brand Hydraulic Pumps. Drives and Motors that are available in the USA. Has a 8,400 lbs operating weight and has lift force of 2940 Ibs. 23.2 GPM flow rate. ~36HP Hydraulic Pump Output. Bucket digging force 6,834 lbs. Arm digging force 4,091 Ibs. Low cost of ownership compared to a big brand unit, which would run you upwards of $84,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Length: 16’ 2”
- Total Height: 8’ 3”
- Total Width: 68”
- Track Width: 12”
- Track Length: 7’
Specifications:
- Max. Digging Depth: 10’ 8”
- Max. Digging Height: 15’ 9”
- Max. Digging Radius: 18’
- Max. Dumping Height: 11’ 2”
Special Order – Price: $42,900
Optional Features:
- 4 way Tilting Dozer Blade $2,200
- 6 way Tilting Dozer Blade $4,400
- Cab located Hydraulic Quick Attach $1,300
- Metal Tracks $2,200
-50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
XH42D Excavator
XH68 Excavator
The 2026 XH68 KYMRON Excavator is our top-of-the-line pro series excavator with luxuries like AC & Heated Cab with a radio. This excavator has a KUBOTA 50 KW Turbo Engine. The XH68 comes with many different options and in different color options. Bucket is 28" wide.
The advantage of KYMRON machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors for easy parts availability. 30 GPM Flow. 67.9HP Hydraulic Pump Output. Machine weighs 13,000 lbs and has lift force of 6000 lbs. Bucket Digging Force 10,990 lbs. Arm digging force 7,990 lIbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $115,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Length: 19’ 6”
- Total Height: 8’ 2”
- Total Width: 78”
- Track Width: 16”
- Track Length: 8’ 4”
Specifications:
- Max. Digging Depth: 12’ 5”
- Max. Digging Height: 19’ 4”
- Max. Digging Radius: 14’ 11”
- Max. Dumping Height: 13’ 10”
Special Order – Price: $57,900
Optional Features:
- 4 way tilting dozer blade $2,900
- Cab located Hydraulic Quick Attach $1,300
- Rubber Track Block System $1,500
-Cab located Hydraulic Quick hitch $1,300
-50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
XH80D Excavator
Pro series excavator with luxuries like Heat/AC & an adjustable seat, along with 2 speed drives. This excavator has a 54KW Kubota Diesel Turbo Engine. The XH80D comes with many different options and in different color options.
This includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to position the boom to dig parallel to walls and fences.
The advantage of XH80D machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors that are available in the USA. This machine has a 16,500 lbs operating weight and has lift force of 7800 Ibs. 33 GPM flow. 72.9HP Hydraulic Pump Output. Bucket digging force is 12,589 lbs and Arm digging force 8,542 lbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $129.000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
- Side Swing Boom
Dimensions:
- Total Length: 23' 7”
- Total Height: 8’ 2"
- Total Width: 86"
- Track Width: 18”
- Track Length: 9' 3"
Specifications:
- Max. Digging Depth: 13' 6"
- Max. Digging Height: 23'
- Max. Digging Outward Reach: 20' 3"
- Max. Dumping Height: 17' 1"
Special Order – Price: $68,600
Optional Features:
- Factory Upgraded Quick Hitch $1,400
- 50% or 20% Black Tint Transparency $650
(3 Year Powertrain Warranty)
XH140 Excavator
2026 XH140 KYMRON Excavator is our top-of-the-line pro series excavator with luxuries like AC & Heated Cab with a radio. This excavator has an 89.4KW KUBOTA Turbo Engine. The XH140 comes with many different options and in different color options.
This includes the factory installed side Swing Feature, which allows you to swing the boom approximately 45° to the left or right to position the boom to dig parallel to walls and fences.
The advantage of KYMRON machines is our exclusive design which is set up to allow name brand Hydraulic Pumps, Drives and Motors for easy parts availability. ~55 GPM Flow. This machine 30,000 lbs operating weight and has a lift force of 12,000 lbs. 120HP Hydraulic Pump Output. Bucket Digging Force 20,457 lbs. Arm digging force 12,364 lbs. Low cost of ownership compared to a big brand unit, which would run you upwards of $240,000.
Upgraded Features:
- Includes HD Hydraulic Thumb
- Upgraded HD Pump
- Upgraded HD Drive Motors
- Auxiliary Hydraulics
- Upgraded Directional Spool Valve
Dimensions:
- Total Length: 25'
- Total Height: 9' 3"
- Total Width: 98”
- Track Width: 20”
- Track Length: 11' 11"
Specifications:
- Max. Digging Depth: 16' 7"
- Max. Digging Height: 28'
- Max. Digging Outward Reach: 26'
- Max. Dumping Height: 20'
Special Order – Price: $136,900
Optional Features:
- Factory Upgraded Quick Hitch $2,400
- 50% or 20% Black Tint Transparency $650
